Caster CAD Models

We provide CAD files in DWG (AutoCAD), STEP, and IGES formats. These formats are compatible with all major CAD platforms including SolidWorks, AutoCAD, Inventor, Fusion 360, CATIA, and Creo.

Yes. Our CAD models are created from manufacturer specifications and reflect accurate overall dimensions, mounting patterns, wheel diameters, swivel radii, and offset measurements. They are intended for use in production design and specification work.

No. All caster CAD models in our library are available for free download. No account or registration is required.

Our CAD library covers a large portion of our catalog and is continuously expanding. If you need a model for a specific caster that is not yet in the library, contact our engineering support team and we will work to provide the file.

Our CAD library includes models for a wide range of caster types including swivel casters, rigid casters, heavy-duty casters, pneumatic casters, and specialty models. Each file reflects accurate overall dimensions, mounting hole patterns, wheel diameters, and swivel offsets so your assemblies and clearance checks are reliable from the first iteration. Files are available for immediate download at no cost.

Having manufacturer-provided CAD data eliminates the guesswork of building caster models from catalog dimensions alone. It reduces design errors, speeds up the specification process, and ensures that the casters you select will fit your application without costly modifications after fabrication. Browse our CAD library by caster type or series, or contact our engineering support team if you need a file for a specific model.
