SBT-1CS - 1" Carbon Steel Ball Transfer with 3/8"-16 x 11/16" Threaded Stud

About This Ball Transfer - SBT-1CS-3/8-16-1

Choose this 1-inch ball transfer when the table is tapped for a 3/8-16 stud, the largest mounting thread in this stud group.

The carbon-steel load ball rides on a bed of smaller steel balls in a housing, letting a box or panel on top move forward, sideways, or rotate in place rather than be lifted and re-aimed. The 3/8-16 threaded stud an inch long is the coarsest, beefiest of the three stud sizes, so it threads into a heavier tapped boss or a thicker plate where a finer stud would feel undersized. The carbon-steel ball is built for a dry indoor table and would rust on a wet line.

Ideal applications

• Heavier tapped bosses and thicker plates taking a 3/8-16 stud
• Transfer tables that move a load in any direction
• Dry indoor packaging and assembly surfaces

For a finer thread on the same 1-inch ball, the 5/16-18 stud SBT-1CS-5/16-18-1 and 1/4-20 stud SBT-1CS-1/4-20-1 step down.

Pairs with: a grid of 3/8-16 stud ball transfers across a heavier transfer table.

Wrong fit? Need a flange or drop-in mount? See the 4-hole flange BT-1-1/2-CS and the drop-in MBT-1CS-1.

Also in this family: the machined-body SMBT-1-CS-1, or the full Hudson Bearings collection.
