5"x2" Cast Iron Swivel Caster - 110CA05201S

About This Caster - 110CA05201S

Fit this 5-inch cast iron swivel to the steering corner of a hot cart that needs more clearance than a 4-inch wheel, where a kingpin loosens under the side load and a soft tread cannot stand the heat.

The 5-inch diameter clears a higher threshold and steers easier over seams than a 4-inch wheel, and Albion's 110 Contender Kingpinless swivel rides a heat-treated raceway with no kingpin to shear or seize. The grey cast iron wheel carries a hard, heavy load from -100 to 800°F, suited to foundry buggies, oven racks, and bakery carts, and the roller bearing turns the load at a slow pace. This is the plain swivel for corners that steer rather than park.

Ideal applications

• Steering corners needing 5-inch clearance on a hot cart
• Foundry and bakery rigs running to 800°F
• High-cycle routes where kingpin swivels seize under shock

For a corner that must hold the cart still, the face-brake 110CA05201SFBC locks the wheel.

Pairs with: the 110CA05201R rigid on the back corners so the front steers and the rear tracks.

Wrong fit? Finished floor, or need a brake? See the polyurethane 110AX05228SFBC and the face-brake 110CA05201SFBC.

Also in this family: the 4-inch swivel 110CA04201S and the 6-inch swivel 110CA06201S, or the full kingpinless caster collection.
